AdBlue, DPF, EGR and DTC off Service for DAF Trucks

The Euro6 version of DAF XF106 series with 12.9L MX-13 engine and the CF series with both MX-11 and MX-13 with Delphi ETC3 ECU model, manufactured from 2013 to 2017 and the facelifted versions from 2017 to 2021.

Common AdBlue Related Fault Codes:

P20EE or SPN4364 SCR efficiency below threshold

P204F or SPN5246 SCR inducement / system performance

P20E8 or SPN4334 FMI 18 AdBlue pressure low

P20E9 or SPN4334 FMI 0 AdBlue pressure high

P207F or SPN3364 DEF/AdBlue quality issue

P2202 or SPN3226 FMI 5 NOx sensor circuit low

P2203 or SPN3226 FMI 6 NOx sensor circuit high

Common DPF System Fault Codes:

P2463 or SPN3251 Excessive soot load

P2452 or SPN102 FMI 3,4 differential pressure sensors

P2453 or SPN102 FMI 2 pressure sensor range/performance

P2458 or SPN3236 regeneration duration excessive

P2002 or SPN3251 FMI 1 DPF efficiency below threshold

P244A or SPN3251 FMI 0 DPF differential pressure high

Common EGR Related Fault Codes:

P0400 or SPN2791 general EGR flow fault

P0401 or SPN2791 FMI 1 EGR flow insufficient

P0402 or SPN2791 FMI 2 EGR flow excessive

P0405 or SPN2791 FMI 4 EGR position sensor low

P0406 or SPN2791 FMI 3 EGR position sensor high

Best ECU Tuning & Diagnostic Tools For DAF Trucks with Delphi ETC3 ECU:

• Two of the best diagnostic tools for DAF trucks is DAF DAVINE and JALTEST.

• KESS3: Kess3 is suitable for DAF XF106 and Kenworth T660 &T680 trucks with MX13 engine (OBD/Boot)
• MAGIC MOTORSPORT FLEX: Flex is suitable for following trucks:

1. DAF CF and XF106 with MX-11 and MX-13 with ETC3 UDS (Unified Diagnostic Services ISO 14229) ECU model (OBD)
2. DAF XF106 with MX-11 and MX-13 with ETC3 KWP (Keyword Protocol 2000 ISO 14230)
3. Kenworth T680, T880, W990 with MX-13 and ETC3 KWP
4. Peterbilt 567 & 579 with MX-11 and MX-13 engine and ETC3 KWP

• BitBox: For various models of DAF trucks, Kenworth, and Peterbilt trucks (DAF/industrial Delphi ETC3 FID:220) (OBD/Bench)

EGR Removal for DAF ETC3 ECU:

• First gather a list of EGR related fault codes in Pcode or SPN format and errors shown on the dashboard
• Read the ECU file using a compatible tool in OBD/Bench/Boot protocol depending on your tool supported protocols and compatibility
• Upload the file with the relative fault codes and errors on our website, we’ll provide the solution within 15 minutes.
• Note: For some calibrations The EGR valve plug must be disconnected, we’ll inform whether it’s necessary to disconnect
• Write the file back to the ECU using the same reading protocol
• Clear fault codes and test drive

If you encounter any trouble in any of above steps you can contact us, our support team will provide guidance as quickly as possible.

DPF Off for DAF ETC3 ECU:

• First gather a list of DPF related fault codes in Pcode or SPN format and errors shown on the dashboard
• Read the ECU file using a compatible tool in OBD/Bench/Boot protocol depending on your tool supported protocols and compatibility
• Upload the file with the relative fault codes and errors on our website, we’ll provide the solution within 15 minutes.
• Note: The DPF temperature and pressure sensors can be disconnected
• Write the file back to the ECU using the same reading protocol
• Clear fault codes, do a forced regeneration and test drive

If you encounter any trouble in any of above steps you can contact us, our support team will provide guidance as quickly as possible.

AdBlue Off for DAF ETC3 ECU:

• First gather a list of AdBlue/SCR related fault codes in Pcode or SPN format and errors shown on the dashboard

• Read the ECU file using a compatible tool in OBD/Bench/Boot protocol depending on your tool supported protocols and compatibility
• Upload the file with the relative fault codes and errors on our website, we’ll provide the solution within 15 minutes.
• Note: For some calibrations The Pump plugs must be disconnected, and some calibrations the fuse190 shall be removed we’ll inform after checking the file.

• Note: The solution will be applied on the ECU file only, thus reading the ACM isn’t required.
• Write the file back to the ECU using the same reading protocol
• Clear fault codes and test drive

If you encounter any trouble in any of above steps you can contact us, our support team will provide guidance as quickly as possible.

Location of Sensors and Actuators:

• Adblue Pump and Tank Location

Adblue Pump and Plug:



Adblue Tank & Pump Location:



EGR Valve:

DAF Trucks Online Adblue, EGR, DPF & DTC Off Service and Pricing

NinjaRemap offers Adblue, EGR and DPF delete services for all model of DAF Trucks. This service is provided only where Adblue, EGR and DPF removal is legally permitted, and for vehicles authorized for such modifications, including racing vehicles, off-road vehicles, transit vehicles and certain fleet vehicles.

At NinjaRemap, Adblue, EGR and DPF removal can be carried out entirely online. Simply read your original ECU file using a compatible flashing tool and send it to us through our ECU tuning service on the website or via WhatsApp. You will receive your modified file in less than 20 minutes.

We will perform the Adblue, DPF and EGR Off and, if required, also remove any related or unrelated fault codes (DTCs). The total cost for all these services, including a 30-day warranty, is only $65.

Send us your file today and get started!
