This article is about TRW EMS 2 and EMS 2.2 the TRW EMS 2 was applied in various models of Euro 4 versions mostly produced from year 2005 until 2009 including Volvo trucks, Renault trucks, and Mack trucks. From 2009 to 2013 TRW EMS 2.2 was used in Euro 5 versions of Volvo trucks, Renault trucks, Mack trucks and some models of Nissan UD trucks.



Common TRW EMS 2 and 2.2 fault codes


Some of the most common emission fault codes are as follows:

P0400: Exhaust gas recirculation” A” flow
P0403: EGR “A” control
P0470: Exhaust pressure sensor “A”
P0475: Exhaust pressure control valve “A”
P2413: EGR system performance
P2002: DPF efficiency below threshold
P2452/P2453: DPF pressure sensor circuit / range
P2454/P2455: DPF pressure sensor low / high
P244A/P244B: DPF differential pressure too low / too high
P2463: Soot accumulation
P242F: ash accumulation
P2458: Regeneration duration
P20EE: SCR NOx catalyst efficiency below threshold
P207F: Reductant quality / performance
P203F: Reductant level too low
P204F: Reductant system performance
P2047/P2048/P2049: Reductant injector circuit open / low / high
P20E8: Reductant pressure too low
P2200-P2203: NOx sensor circuit / range / low / high
P202A: reductant tank heater control circuit


Best tools to read TRW EMS2 and2.2

Alientech KESS3 (Suitable for vehicles with EMS2 (OBD/Boot) and EMS2.2 (OBD/Bench/Boot)

Dimsport NEW TRASDATA (Suitable for EMS2 and EMS2.2 (Bench/ Boot))

Dimsport NEW GENIUS (Suitable for EMS2 and EMS2.2 (OBD))

MAGICMOTORSPORT FLEX (Suitable for EMS2 (Boot) and EMS2.2 (Bench/Boot))

For OBD read you can connect your tool to the vehicles OBD port and read and write the file if your tool supports Bench mode either you can remove the ECU and read and write it on Bench however some companies like alientech have "Cable for Volvo TRW Bench connection" which you can purchase and connect them to the ECU without needing to dismount the ECU.

Reading TRW EMS2.2 via Bench mode using FLEX

TRW EMS ECU mounted on the Engine

 Cable for Volvo TRW Bench connection from Alientech



Reading ECU using Kess3 with adapter in bench mode

ECU tuning solutions for TRW EMS2 and EMS2.2

Trucks with TRW EMS2 are mostly Euro 4 thus they only have Diesel particulate filter and EGR valve. but later trucks with TRW EMS2.2 which produced since 2010 were equipped with SCR system and in earlier versions mostly until 2011, the SCR system was controlled by the ECU.
Later trucks from 2012 or some 2013 models with TRW EMS2.2 equipped with ACM.

EGR removal solution

  1. First use a scanner or any diagnostic tools and provide us the EGR related fault codes.
  2. Read the file using a compatible tool in OBD or bench mode or boot mode depending on the tool compatibly.
  3. Upload the file on your dashboard with the EGR related DTCs.
  4. Our team will work on the file and within 20 minutes you’ll receive your file on your dashboard.
  5. Write the file using the same reading Protocol.
  6. Clear fault codes.

DPF removal solution

  1. First use a scanner or any diagnostic tools and provide us the DPF related fault codes.
  2. Read the file using a compatible tool in OBD or bench mode or boot mode depending on the tool compatibly.
  3. Upload the file on your dashboard with the DTCs attached.
  4. Our team will work on the file and within 20 minutes you’ll receive your file on your dashboard.
  5. Write the file using the same reading Protocol.
  6. Clear fault codes.
  7. For this solution you can disconnect the dpf temperature and pressure sensors.

SCR removal solution

  1. First use a scanner or any diagnostic tools and provide us the SCR and NOx related fault codes.
  2. Read the file using a compatible tool in OBD or bench mode or boot mode depending on the tool compatibly.
  3. Upload the file on your dashboard with the DTCs attached.
  4. Our team will work on the file and within 20 minutes you’ll receive your file on your dashboard.
  5. Write the file using the same reading Protocol.
  6. Clear fault codes.
  7. Note: The AdBlue fuse should be disconnected for the solution to work.



EGR valve location

EGR valve location
In volvo d13 versions which share many parameters with mack mx8 and de13 from Renault. The egr vale actuator is located near the turbocharger.
If you check the below picture the EGR valve cooler is located below the turbocharger and the egr valve itself is connected to the EGR valve cooler and it’s next to the turbocharger.





EGR valve actuator location in Volvo D13 engine


In volvo trucks VN series the DPF is located on the left side of the truck and after removing the panel you can get access to the diesel particulate filter with the sensors connected to it and SCR system.

Volvo VN series remove side panel to access to DPF and SCR



Volvo FH series DPF access



after removing the side panel in VN series you'll get access to DPF and SCR, there are the sensors connected to the DPF including DPF temperature sensors and pressure sensor.





AdBlue module fuse in later models

Later models from 2012 to 2013 have Euro 6 Emission standards These models have Aftertreatment control module.

SCR system with the ACM module location.



The SCR fuse is a 30A rated fuse with FT01 code.

TRW EMS2, EMS2.2 Online Adblue, EGR, DPF & DTC Solution Service and Pricing:

NinjaRemap offers Adblue, EGR and DPF solution services for all model of trucks with TRW EMS2, and EMS2.2. This service is provided only where Adblue, EGR and DPF solution is legally permitted, and for vehicles authorized for such modifications, including racing vehicles, off-road vehicles, transit vehicles and certain fleet vehicles.

At NinjaRemap, Adblue, EGR and DPF solution can be carried out entirely online. Simply read your original ECU file using a compatible flashing tool and send it to us through our ECU tuning service on the website or via WhatsApp. You will receive your modified file in less than 20 minutes.

We will perform the Adblue, DPF and EGR solution and, if required, also remove any related or unrelated fault codes (DTCs). The total cost for all these services, including a 30-day warranty, is only $65.

Send us your file today and get started!
